| Type |
Uncooled Focal Plane Detector |
| Customized Support |
OEM, ODM |
| Place of Origin |
Hubei, China |
| Power |
other |
| Logo/graphic design |
hot stamping, 3D Printing |
| Accuracy |
Ultra high level |
| Voltage |
20V – 32VDC |
| Protection Class |
IP54 |
| Warranty |
1 Year |
| Brand Name |
Shendu |
| Application |
security survillence |
| Product Name |
Pod Shendu Camera |
| Application |
Payloading integration |
| Model Number |
PD280TA |
| Packaging & Delivery |
Single item |
| Infrared Thermal Imager |
| Model |
PD280TA |
| Detector Type |
Uncooled Focal Plane Detector |
| Working Waveband |
8μm～14μm |
| Detector Resolution |
640×512 |
| Pixel Size |
12μm |
| Lens Focal Length |
20mm～100mm |
| Field of View |
21.7°×17.5°～4.4°×3.5° |
| Palette |
6 |
| Noise Equivalent Temperature Difference |
NETD≤50mK |
| Minimum Resolvable Temperature Difference |
MRTD≤500mK |
|
|
| Visible Light Camera |
| Resolution |
1920×1080 |
| Pixel Size |
2.8μm |
| Optical Zoom |
15 times |
| Hybrid Zoom |
30 times |
| Focal Length |
12mm～185mm |
| Field of View Angle |
25°×14°～2°×1° |
| Zoom |
Auto focus, manual focus |
| Minimum Illumination |
0.01Lux |
|
|
| Laser Ranging Machine |
| Maximum Ranging Distance |
≥4km (under the condition of visibility ≥15Km) |
| Minimum Ranging Distance |
≤20m |
| Ranging Accuracy |
≤2m |
| Ranging Frequency |
1 ~5 Hz |
| Laser Radiation |
80mJ |
|
|
| Servo Platform |
| Pan Angle |
360°×n (360° continuous rotation) |
| Tilt Angle |
-110° ~ +20° (positive upward) |
| Angular Position Accuracy |
≤1mrad（1σ） |
| Stabilization Accuracy |
≤0.1mrad(1σ) |
| Tracking Accuracy |
≤1mrad(1σ) |
| Maximum Tracking Angular Velocity |
≥10°/s |
| Maximum Turning Speed |
azimuth≥90°/s，pitch≥90°/s |
| Maximum Turning Acceleration |
azimuth≥90°/s²，pitch≥90°/s² |
|
|
| System parameters |
| Image Tracking |
Automatically track selected targets |
| AI Recognition |
Auto checking, identify typical target |
| Rated Working Voltage |
24VDC |
| Voltage |
20V – 32VDC |
| Consumption |
Stable Power Consumption: ≤100W, summit consumption：≤300W |
| Weight |
≤19Kg |
| Dimensions |
≤280mm×280mm×485mm |
|
|
| Interface |
| Control Interface |
RS422/Mbps network |
| Video Interface |
HD-SDI/Mbps network |
| Storage Interface |
≤128G Memory Card (Mini SD Card) |
| Picture Format |
jpg Format |
| Video Format |
avi Format |
|
|
| Environmental Adaptability |
| Working Temperature |
-40℃～＋60℃ |
| Storage Temperature |
-40℃～＋60℃ |
| Vibration Condition |
Acceleration of 2g; 30 minutes in each of the vertical, lateral and longitudinal directions. |
| Impact Condition |
Peak acceleration of 20g, duration of 11ms |
| Protection Level |
Can fly in light rain |
|
|
|
|
|
|
|
|
|
|
|
|
